Meade AC 70/700 Infinity AZ Telescope
Designed for introductory visual astronomy, the Meade AC 70/700 Infinity AZ Telescope combines a 70mm achromatic refractor with 700mm focal length and manual panhandle alt-azimuth movement.
- 70mm aperture provides 1.65-arcsecond resolution
- 700mm focal length uses f/10 optics
- Alt-azimuth mount includes slow-motion control
- 27x and 78x eyepieces included
- 2x Barlow and software included
In Stock
Description
Portable wide-field observation begins with the Meade AC 70/700 Infinity AZ Telescope, an achromatic refractor with a 70 mm aperture, 700 mm focal length, and listed f/10 optical ratio. Its manual panhandle alt-azimuth mount uses a slow-motion altitude rod, while the multi-coated optics, red dot finder, 90-degree erect-image diagonal, 26 mm and 9 mm eyepieces, 2x Barlow lens, aluminum tripod, accessory tray, and AutoStar Suite software support lunar, planetary, and terrestrial viewing.
The upright diagonal allows suitable daytime landscape observation, while the 700 mm focal length supports the supplied lunar and planetary application. The manual mount does not require batteries or computerized alignment, and the plastic focuser, optical tube, tripod, eyepieces, and diagonal should be stored clean and dry and protected from impact during transport and repeated setup.
Key Features of Meade AC 70/700 Infinity AZ Telescope
This manual achromatic refractor combines a 70 mm aperture with a 700 mm focal length, f/10 optical ratio, panhandle alt-azimuth mount, slow-motion altitude control, upright diagonal, red dot finder, two eyepieces, Barlow lens, tripod, accessory tray, and astronomy software.
- 70 mm achromatic refractor
- 700 mm focal length with listed f/10 optical ratio
- Manual panhandle alt-azimuth mount
- Slow-motion altitude control rod
- 26 mm and 9 mm eyepieces
- 2x Barlow lens
- Red dot finder and erect-image diagonal
- Aluminum tripod, tray, and AutoStar Suite software
Manual Lunar and Terrestrial Observation
The supplied application focuses on lunar contours, planetary targets, bright star patterns, and suitable daytime landscapes, with the 700 mm focal length supporting the listed long-focus refractor format while the erect-image diagonal provides an upright view and the panhandle mount allows direct manual positioning without electronic tracking.
Why Choose Meade AC 70/700 Infinity AZ Telescope
The Infinity 70 is relevant when a straightforward telescope is needed for lunar and planetary viewing together with daytime terrestrial use, because it combines a manual panhandle mount, upright diagonal, multiple eyepieces, Barlow lens, finder, adjustable tripod, accessory tray, and software in a complete configuration that requires no batteries.
- Manual day-to-night operation with upright viewing
- 700 mm focal length for lunar and planetary observation
- Eyepieces, Barlow lens, finder, diagonal, tripod, tray, and software included
Meade 1-Year Limited Warranty
The supplied product information lists a 1-year limited warranty for this telescope, and the applicable US warranty terms, optical coverage, mount coverage, accessory coverage, registration requirements, and authorized service process should be confirmed through the current Meade seller or distributor before purchase.
Meade AC 70/700 Infinity AZ Telescope Specs
| Brand | Meade Instruments |
| Full Model Code | Meade Infinity 70mm Alt-Azimuth Refractor Telescope (216002) |
| Country of Origin | United States / China |
| Optical Design | Achromatic Refractor (Doublet Objective System) |
| Aperture | 70 mm (2.75 inches) |
| Focal Length | 700 mm |
| Focal Ratio | f/10 |
| Optical Coatings | Multi-Coated Anti-Reflective Optical Elements |
| Glass Material | Standard Crown and Flint Optical Glass Core |
| Secondary Mirror Obstruction | 0 mm (None) |
| Secondary Mirror Obstruction by Diameter | 0% |
| Secondary Mirror Obstruction by Area | 0% |
| Resolving Power | 1.65 Arcseconds (Dawes), 1.97 Arcseconds (Rayleigh) |
| Limiting Visual Magnitude | 11.3 |
| Highest Useful Magnification | 140x |
| Lowest Useful Magnification | 10x |
| Optical Tube Material | Powder-Coated Aluminum Structural Barrel Shell |
| Focuser Style & Mechanism | 1.25-inch ABS Plastic Rack and Pinion Focuser Configuration |
| Mirror Lock Mechanism | No |
| Optical Tube Dimensions | 73 mm x 685 mm |
| Optical Tube Weight | 1.10 kg (2.43 lbs) |
| Mount Attachment Type | Integrated Panhandle Alt-Azimuth Yoke Mount with Slow-Motion Altitude Control Rod |
| Finder Scope Specification | Red Dot Finder Scope Assembly with Fixed Plastic Bracket Mount |
| Included Accessories | Alt-Azimuth Mount with Pre-assembled Aluminum Tripod, Accessory Tray, Red Dot Finder, 90-Degree Erect-Image Diagonal (1.25-inch), MA 9mm Eyepiece (78x), MA 26mm Eyepiece (27x), 2x Barlow Lens, Autostar Suite Astronomy Software DVD |
| Standard Warranty | 1-Year Limited Warranty |
| Application | Entry-level astronomical tracking and terrestrial landscape monitoring, adopting a native f/10 ratio to mitigate secondary spectrum aberration lines and present sharp lunar contours. |
