TS Optics Jupiter AC 70/900 EQ3-1 Telescope Specs
| Brand | TS Optics (Teleskop-Service) |
| Full Model Code | TS Optics Jupiter 70 mm f/12.8 Achromatic Refractor Complete Equatorial Telescope System |
| Country of Origin | China (Manufacturing Execution) / Germany (Design / Quality Control Oversight) |
| Optical Design | Achromatic Refractor (2-Element Crown and Flint Air-Spaced Fraunhofer Objective Layout) |
| Aperture | 70 mm (2.76 inches) |
| Focal Length | 900 mm |
| Focal Ratio | f/12.85 |
| Optical Coatings | Standard Multi-Coated Anti-Reflective layer coatings across all structural air-to-glass lens borders |
| Glass Material | Standard Grade Crown-Flint Achromatic Optical Glass Matrix engineered for long focal path target definition |
| Secondary Mirror Obstruction | 0 mm (Unobstructed Optical Path Setup) |
| Secondary Mirror Obstruction by Diameter | 0% |
| Secondary Mirror Obstruction by Area | 0% |
| Resolving Power | 1.65 Arcseconds (Dawes), 1.97 Arcseconds (Rayleigh) |
| Limiting Visual Magnitude | 11.0 |
| Highest Useful Magnification | 140x |
| Lowest Useful Magnification | 10x |
| Optical Tube Material | Lightweight Roll-Formed Aluminum Main Tube fitted with protective internal contrast baffling walls |
| Focuser Style & Mechanism | 1.25-inch Precision Rack and Pinion Focuser featuring dual control wheels and manual lock thumb screws |
| Mirror Lock Mechanism | No (Equipped with standard manual structural mechanical lock screws) |
| Optical Tube Dimensions | 72 mm x 870 mm (Tube Outer Diameter x Total Working Physical Assembly Length Profile) |
| Optical Tube Weight | 2.00 kg (4.41 lbs) (Chassis weight measurement omitting downstream secondary mounting brackets) |
| Mount Attachment Type | Integrated Structural Tube Clamps bolted directly to a standard equatorial saddle platform array |
| Finder Scope Specification | 6x30 Optical Finder Scope module mounted on an adjustable secondary quick-release foot block |
| Included Accessories | 70mm Optical Tube, EQ3-1 Equatorial Mount, Height-Adjustable Aluminum Tripod, 6x30 Finder, 20mm and 10mm Plössl Eyepieces, 2x Barlow Lens, Star Diagonal |
| Standard Warranty | 2-Year Limited Warranty |
| Application | Entry-level lunar, planetary, and bright double-star observation, featuring an extended f/12.8 focal path that minimizes standard achromatic color fringing. |
